Standard Emissionsmesssysteme
HORIBA Abgasanalysesysteme haben einen Anteil von 80% am Weltmarkt. Durch ihre hohe Präzision erfüllen oder übertreffen sie alle weltweiten Anforderungen hinsichtlich der Messgenauigkeit.
Seit ihrer Einführung im Jahr 1995 wird die MEXA-7000 Baureihe von der Automobilindustrie eingesetzt und geschätzt. Mit der dritten Generation des MEXA-7000 wurde die Serie weiterentwickelt und verbessert. Die MEXA-7000 Version 4 erfasst Abgasemissionen verschiedenster Treibstoffe und Verbrennungsmotoren.
Simultaneous Measurement of Four Nitrogen Compounds with High Accuracy - For Certification and R&D of advanced NOx after-treatment systems
An analyzer system designed for the continuous measurement of a wide range of exhaust gas concentrations from all types of engines including automotive, marine, jets...even lawn mowers.
A fast response analytical system for raw exhaust emissions from diesel or gasoline (4-cycle) engines.
MEXA-7200SLE accurately analyzes extremely low levels of CO, THC, NOx, and CH4
Laboratory-grade analytical emissions system designed to measure raw exhaust gases from internal combustion engines. Single cabinet includes PC-based flow controller and sampling system as well as analyzers for measuring CO, CO2, THC, NOx, O2 and (optionally) EGR-CO2.
One of the newest additions to the HORIBA stand alone analyzer product family is the MEXA-1170HCLD, which uses an industry standard chemiluminescence detector for NO/NOx measurement.
This single-component measurement system measures total hydrocarbons with a heated flame ionization detector. Designed for stand-alone operation, MEXA-1170HFID includes a detector, sampler, and control system in a compact, rack-mountable case. The detector is based on MEXA-7000FID, providing proven reliability and accuracy.
The MEXA-1170NX is an ideal tool for measuring NH3 in the development of various NOx reduction technologies such as selective catalytic reduction (SCR), Lean NOx traps (LNT) and three way catalysts. It measures NH3 in real time with high sensitivity using twin chemiluminescence (CLD) detectors with an NH3 oxidizing oven. In addition to standalone measurement of NH3, NO and NOx, it can be integrated as an additional analyzer with the MEXA-7000 series.
The MEXA-1170SX is a continuous gas analyzer for sulfur compounds existing in engine emissions. It can measure concentrations of SO2and total reduced sulfur compounds (TRS), such as H2s, separately. It can also measure the total sulfur compounds (TS) that contain both gaseous compounds and liquid compounds in PM, such as SO3. "Lubricant oil consumption" measurement using sulfur trace method is also available.
