ABX Pentra ML

Centralized Validation

Product Description

Process efficiency in Hematology

An all-in-one validation system entirely dedicated to whole blood

A scalable and adaptable solution to meet your requirements:

  • Reduced slide review
  • Standardization of laboratory practice
  • Increased productivity
  • Optimization of the accreditation procedure
Segment: Medical
Division: Hematology
Base product
Manufacturing Company: HORIBA ABX SAS

Software

Quality Control Management

  • Hematology-dedicated QC (multi-level management and collection of lots, presentation of results line by line, XB, Repeatability, Levey-Jennings graphs, etc.)
  • Simultaneous viewing of your controls at 3 different levels
  • Connectivity with your inter-laboratory comparison program

 Standardization of your laboratory guidelines

  • Inter-runs comparisons whatever the instrument (same technology shared across the product range)
  • Reagent standardization
  • Control & calibrator compatible
  • Sharing of identical rules between the central laboratory and all the satellite laboratories
  • Comprehensive catalogue of integrated and customizable multi-criteria rules (validation, re-runs, reflex testing, printing, comments, diagnosis, etc.)
  • Management of complementary reflex testing: Blood counts (Reticulocytes, Erythroblasts), cytology (manual slides or HemaCAM)
  • ISLH diagnostic analysis guidelines

 Optimized decision-making

  • Support for manual validation with centralization of key information (manual and instrument results, anteriority, cell pictures, etc.)
  • Display of current and previous runs
  • Matrix monitoring of pathology evolution
  • Automatic multi-criteria validation of results: Qualitative, Quantitative, Delta check, Demographics, Physician, Comments, etc.
  • Priority given to Delta check

Logs

Reagents, quality controls, calibration, maintenance, data handling, settings, communication, errors, blank

Patient Management

  • Automatic validation (setting rules)
  • Patient history (Matrix, curves, data) and Demographic controls
  • Handles stat management
  • Manual entry
  • Automatic back-up of archives using an external media

User Tool – Learning support

  • Integrated cytology atlas : Hematovision
  • Integrated user manual

Connections

Fully compatible with the entire HORIBA ABX Pentra hematology range

  • ABX Pentra DX 120, ABX Pentra DF 120
  • ABX Pentra XL 80, ABX Pentra 80
  • ABX Pentra 60 C+, ABX Pentra 60
  • ABX Micros

Technical

Processor

Pentium® 3.0 GHz

Flat Screen

LCD 20 inch

On-line memory capacity

25,000 results + graphics
100,000 results (without graphics)

Data processing

Windows XP External PC
RAM (4 Gb), Hard disk (320 Gb)
Floppy disk & DVD reader
Parallel port + RS 232C, USB ports, Ethernet card
Bi-directional connections

Compliance

ASTM protocol

Optional HemaCAM

Network card

24 inch screen

Data Management
Data Management
Data management includes software and services that provide an interface between in vitro diagnostic (IVD) instruments and Laboratory Information System (LIS) or between instruments in the same work area.
