CAMSIZER P4*

Dynamic Image Analysis System Particle Size

The CAMSIZER® P4 Digital Image Processing Particle Size and Shape Analysis System provides rapid and precise particle size and particle shape distributions for dry powders and bulk material in the size range from 20 µm to 30 millimeters. This technique provides a wide variety of information about the sample, from a general size measurement, to shape parameters that can be closely correlated to specific performance characteristics. This also allows correlation to existing data from techniques as diverse as sieving, microscopy, and hand caliper measurement.

The CAMSIZER® P4 is a compact laboratory instrument for simultaneous measurement of particle size distribution and particle shape, number and density of powders and granules. The patented design is the only one to use two cameras and greatly extends the measurement range while maintaining accuracy and sensitivity throughout.

Thanks to the unique scanning of all particles and the newly developed fitting algorithms, the measuring results are 100% compatible to those of sieve analysis. This makes the CAMSIZER® P4 the ideal time and cost-saving alternative for incoming and outgoing controls and for in-process quality control.

Application Examples: abrasives, carbon products, pelletized carbon black, coffee, catalysts, fertilizers, food products, glass/ceramics, metal powders, pharmaceuticals, plastics, polystyrene, refractory products, salt, sand, sugar, and many others.

The CAMSIZER is manufactured by Retsch Technology GmbH and distributed in many parts of the world by HORIBA.

*Available in select countries.

Segment: Scientific
Manufacturing Company: Retsch Technology GmbH
  • Improved data correlation to sieve analysis, including multi-modal distributions.
  • Sample optimized, intuitive software.
  • Additional shape parameters including sphericity, aspect ratio, convexity, symmetry, roundness, elongation, circularity, and surface texture analysis.
  • Language versions including English, German, French, Japanese, and Spanish.
  • Wide Size Range: 20 µm to 30 millimeters in one measurement with no hardware changes required; a 1500:1 dynamic range.
  • Measurement Principle: The instrument employs digital image processing to measure size, shape, number and density of solid particles.
  • High Resolution: Two linked, high resolution, full-frame cameras, with different resolutions, operating simultaneously, form an intelligent measuring system with a very wide dynamic range while still capturing images of all particles in the sample.
  • Monitor the particle size distribution with real-time calculation during the measurement
  • Image acquisition at 60 frames per second
  • High-intensity, long life stroboscope LED light source
  • Automatic sheeting air to keep camera and light source windows clear of dust
  • Automatic measurement chamber vacuum eliminates velocity biasing by maintaining equal particle velocity independent of size, shape or density
  • Sample introduction via automatic speed-controlled vibratory feeder
  • Automatic feeder hopper height control
  • 30 seconds to 4 minute analysis time, depending on sample type
  • ISO-traceable certified calibration reticle with a particle size distribution of 60 microns to 14 mm (maximum inaccuracy of 0.1 microns per object).
  • Every particle is analyzed from each pixel to each other pixel in all orientations before binning into 64 classes.
  • High resolution analysis in at least 1,000 up to 3,000 saved, size classes per run.
  • Ten user-selectable measurement size models for superb correlation to particle width, particle length or equivalent area to get excellent correlation to results from laser scattering, hand caliper measurements and sieve analysis.

  • Size Range: 20 µm - 30 mm with no hardware adjustments
  • Excellent dynamic range for measuring wide particle size distributions
  • High resolution for narrow mono-modal or multi-modal distributions
  • Reliable detection of smallest amounts (<0.01%) of oversized grains
  • Particle shape analysis (e.g. detection of agglomerates, broken particles or contaminations)
  • Flexible data evaluation thanks to the particle library and 3D Cloud
  • Fully comparable to sieve analysis results
  • Excellent reproducibility

Size and Shape of Salt using Dynamic Image Analysis
Size and Shape of Salt using Dynamic Image Analysis
Many salt producing facilities have now switched to dynamic image analysis (the CAMSIZER), which is quicker, more efficient, and provides additional information about the shape of the salt crystals. This application note describes how the CAMSIZER has been successfully used to characterize salt size and shape.
Frac Sand and Proppants
Frac Sand and Proppants
Hydraulic fracturing is used in the oil and gas industry to increase the flow of oil and/or gas from a well. Proppants are pumped into the oil well with fracturing fluid to hold the fissures open. The proppant size, shape, and mechanical strength influences the integrity of the newly created fractures, and therefore the flow of oil and gas out of the well.
Particle Size and Shape of Detergent Powder
Particle Size and Shape of Detergent Powder
This application note describes how the CAMSIZER has been successfully used to characterize detergent powder size and shape.
Particle Size and Shape Analysis of Coffee
Particle Size and Shape Analysis of Coffee
Few products are so involved in particle sizing from start to finish as coffee. From the classification of the raw, green coffee bean to the relationship between brew quality and the size of ground coffee beans, the quality of the final coffee drink is directly related to particle size and sometimes shape and density as well.
Determination of Particle Size and Shape of Pharmaceutical Granules
Determination of Particle Size and Shape of Pharmaceutical Granules
In this study, dynamic image analysis is used in the pharmaceutical industry to define the size and shape of granules created through a dry granulation process.
Particle Characterization and Quality Control of Sugar Crystals and Powdered Sugar
Particle Characterization and Quality Control of Sugar Crystals and Powdered Sugar
Quality control is an essential part of sugar production. In this work, particle size of crystal sugar and commercial powdered sugar will be discussed.
Particle Size and Shape Analysis of Sand
Particle Size and Shape Analysis of Sand
Traditional sieve measurements are being replaced with automated digital image analysis. Successful incorporation of digital image analysis often includes data correlation to sieve results, followed by realizing the advantages offered by this technique.
Fertilizer Applications
Fertilizer Applications
Fertilizers are chemical compounds given to plants to promote growth. The particle size of fertilizer materials directly affects release rate, potency, and working hazards such as dust generation.
Particle Size and Shape Analysis of Activated Carbon
Particle Size and Shape Analysis of Activated Carbon
Dynamic image analysis has proven useful for the size and shape analysis of many forms and grades of activated carbon and has successfully replaced older techniques around the world.
Particle Size Analysis of Polymers
Particle Size Analysis of Polymers
The combination of laser diffraction and dynamic image analysis systems supplies a wide dynamic range, fast material analysis, and easy data interpretation for the majority of polymeric materials.
Measurement of Particle Size of Cement and Concrete Components
Measurement of Particle Size of Cement and Concrete Components
The final properties of the concrete body are determined by a number of properties. This note addresses the effects of particle size in cement manufacturing and in the final product.
Determination of the Roundness of Globules in the Pharmaceutical Industry
Determination of the Roundness of Globules in the Pharmaceutical Industry
For determination of grain size and roundness of globules, quick and objective measurement methods are required to guarantee high analytical accuracy as well as high product throughput.
Production Control of Sugar using the CAMSIZER Digital Image Analyzer
Production Control of Sugar using the CAMSIZER Digital Image Analyzer
The use of the CAMSIZER digital image analysis system is a useful tool to achieve production optimization in sugar manufacturing.
Production Control of Polystyrene Beads
Production Control of Polystyrene Beads
For free-flowing materials like polymer beads, the CAMSIZER is greatly suitable for use in production, as it guarantees rapid measurements, simple operation and robustness to vibration and dust.
