Spectroscopy Solutions - Imaging Scientific Cameras

Affordable and high performance EMCCD and CMOS cameras

HORIBA is pleased to introduce three new low light level monochrome imaging cameras. Dedicated to low light imaging applications such as fluorescence imaging, astronomy, and single molecule detection, the EFiS, AToR, and IRiS are ideal candidates when photons are scarce or fast temporal acquisition is required. Taking advantage of the latest Scientific CMOS and EMCCD technology, these cameras offer excellent performance at affordable prices.

To find cameras designed for use in spectroscopy with HORIBA monochromators, click here.

Segment: Scientific
Division: Custom Spectroscopy Solutions
Base product
Manufacturing Company: HORIBA Scientific

Primary Applications

Imaging cameras are used in conjunction with a variety of compatible electro-optical components and software to build custom imaging solutions.

  • Solar / Photovoltaics
  • Astronomy
  • Calcium signaling
  • Fluorescence imaging
  • Flow cytometry
  • FRAP
  • FRET
  • Genome sequencing
  • High content screening
  • High resolution fluorescence imaging
  • Hyperspectral imaging
  • LIBS
  • Live Cell imaging
  • Single molecule detection
  • TIRF


EFIS

AToR

IRiS

Type

Scientific Frame Transfer EMCCD

Scientific Interline EMCCD

Scientific CMOS

Active Pixels

1004 x 1002

658 x 496

2048 x 2048

Pixel Size

8 μm x 8 μm

10 μm x 10 μm

5.5 μm x 5.5 μm

Frame Rate

30 Hz

50 Hz

37.5 Hz

Readout Noise

<1 e

<1 e

<7 e

Spectral Response

180 – 1100 nm

350 – 1100 nm

350 – 1100 nm




Synapse-i

Type

Scientific Full Frame CCD

Active Pixels

515 x 512

1024 x 1024

Pixel Size

24 μm x 24 μm

13 μm x 13 μm

Image Readout Time

20 kHZ

15.8 s

63 s

1 MHz

0.32 s

1.5 s

Readout Noise

20 kHZ

3 e- rms

2 e- rms

1 MHz

15 e- rms

8 e- rms

Spectral Response

200 – 1100 nm

EFIS Specification Sheet
CategoryDocuments
Size 1.54 MB
FiletypePDF
AToR Specification Sheet
CategoryDocuments
Size 1.54 MB
FiletypePDF
IRiS Specification Sheet
CategoryDocuments
Size 1.54 MB
FiletypePDF
Synapse-i 512x512 Specification Sheet
CategoryDocuments
Size 0.68 MB
FiletypePDF
Synapse-i 1024x1024 Specification Sheet
CategoryDocuments
Size 0.68 MB
FiletypePDF
