Weight: | 17 kg |
Power supply: | 100 V - 240 V(+/-10%) - 50 Hz to 60 Hz |
Dimensions (HWD): | 43 x 36 x 35 (cm) |
Printer: | Built-in thermal printer +80 column Dot Matrix Printer |
Throughput | 60 tests/hour (OT) |
Data Management: |
Complete QC menu, logs (reagents, calibration, maintenance, errors, blank cycle), easy data transfer (USB), Transmission of patient & QC results to LAN (local area network), Mono-directional connection, All-in-one QC import, overlapping |
Memory: | Last result + 1,00,000 patients results |
Screen: | LCD colour touch screen 8.0’ |
Samples
Parameters (22) | WBC, LYM# & LYM%, MON# & MON%, GRA# & GRA%,RBC,HGB,HCT,MCV,MCH,MCHC,RDW-CV,RDW-SD,PDW-CV,PLT,MPV,PCT, P-LCC,P-LCR,GLR |
Graphics: | PLT,RBC,WBC curves |
Blood volume: | CBC + 3 Part DIFF mode: 10 μL |
Operating sample mode: | Open tube |
Identification: | Alphanumeric, Integrated barcode reader |
Results
Parameters | Presicion (cv %) | Linearity |
WBC | 2.5 (at 10.0 x 103/mm³) | 0 - 150 x 10³/mm³ |
RBC | 2.0 (at 5 x 106/mm³) | 0 -18 x 106/mm³ |
HGB | 1.6 (at 15 g/dL) | 0 - 30 g/dL |
HCT LYM % MON% GRA% | 2.0 (at 45 %) 5.0 5.0 5.0 | 0 - 90%
|
PLT (whole blood) |
| 0 - 6000 x 10³/mm³ (whole blood) 0 - 6000 x 10³/ mm³ (PLT concentrate) |
Blood Controls
Reference | Description |
|
2042208 | ABX Minotrol 16 - 2L | 2 x 2.5 mL vial |
2042202 | ABX Minotrol 16 - 2N | 2 x 2.5 mL vial |
2042209 | ABX Minotrol 16 - 2H | 2 x 2.5 mL vial |
Calibrators
Reference | Description |
|
2032002 | ABX Minocal | 2 mL vial |
