This software can load measured data from pH Meters, F-70 series, Conductivity Meters, DS-70 series, and Portable pH/Water Quality Meters D-70/ES-70/OM-70 series into your PC and save the data in MSD format or BME format or CSV format. Files of MSD format and BME format are the binary files that only open by this software.
F-71/72/73/74/74BW, DS-71/72, D-72/73/74/75, ES-71, OM-71
Refer to "2.4 Necessary PC environment and recommended PC environment"
Optional for Meter(Part No. 3014030151)
Optional for Meter(Part No. 3200373941)
Serial and USB communication
By connecting cable, real-time measurement (reger to "8 Measurement Mode") are enabled as well as the data memorized in the Meter can be acquired by PC (refer to "9 Memory data Mode")
Necessary PC environment and recommended PC environment
The following shows the necessary PC environment and recommended PC environment for this software.
Necessary PC environment: The following PC environment is necessary to use this software.
Recommended PC environment: The following PC environment is recommended to use this software comfortably.
Necessary PC environment
Recommended PC environment
32 bit: 1 GB or more
1 GHz or more
Free space of HDD
5 GB or more
10 GB or more
Windows 7, Windows 8 (8.1), and Windows 10
SUPER VGA (800×600) or more
Serial connector (D-SUB 9 pin)
When this software is used in the condition in which memory or the free space of hard disk is in short, the software may freeze during use and the data cannot be saved.
FD-70(E) instruction manual
Data Collection Software FD-70 Instruction Manual（GZ0000276836D) 0.9MB
Data Collection Software FD-70
For U-50 Series
Please download all attached files, and install the software (section 3.1 of the manual) and drivers (section 3.2 of the manual).
For Windows 7,8,10
