Yumizen P8000

Improve the laboratory workflows and Automatize the results' validation

Product Description

  • Connects Yumizen H1500/H2500 analyzers range
  • Middleware and expert validation station
  • Centralizes the data Management and LIS connections
  • ISLH and/or User definable rules: rerun, reflex testing, comments and validation
  • Dashboard monitoring
  • Web based application
  • Real time alerts of Key Performance Indicators
Segment: Medical
Division: Automation (Medical)
Base product
Manufacturing Company: HORIBA ABX SAS
  • High automatic validation ratio reached thanks to efficient rules package
  • Complete traceability (tube status, sample, reagent, control, analyzer, user actions, all runs with graphs and comments, timing, logs)
  • Adaptable windows, user-friendly and intuitive interface, multi languages software, dedicated user interface settings
  • Tailor-made rules adapted to standardized operating laboratory procedures



Connectivity

Web application

Client / Server model

Protocols

ASTM E1394 (Devices)

HL7 v2.5 (LIS)

Available Drivers

Yumizen H1500

Yumizen H2500

Yumizen H2500 SPS

Standard Connections Capacity

6 Analyzers

1 LIS

5 Simultaneous users

Ports

8 or 16 switchable ethernet ports based on customer configuration

Software

Languages: English (US/UK), French, German, Italian, Spanish, Polish

Remote access

Integrates more than 190 rules and especially ISLH rules

Server Hardware

Model

Dell® PowerEdge T130

Processors

Intel® Xeon E3 - 1220 v5

3 GHz

8M cache

Operating System

Linux® Oracle 64bits distribution

Database

PostgreSQL

RAM

8 Gb UDIMM

Hard drives

3 hard drives of 1Tb Magnetic Sata

6 Gbit/s

7200 tr/min

2 RAID for daily routine and 1 for archive

Connectors

2 ETH

3 USB v3.0

4 USB v2.0

1 RS232

1 VGA

Daily workflow capacity

3 000 tests / server

Storage

Up to 800 000 results per server

Dimensions (HWD)

36 x 17.5 x 43.5 (cm)

Workstation hardware

Model

Dell® Optiplex 3040 Micro XCTO

Processor

Intel® Celeron G3900T, Dual Core, 2.6 GHz, 2M cache

Operating system

Windows® 7 professional 32 bits

RAM

4 Gb 1600 MHz DDR3

Hard Drive

128 Gb SSD Sata

6 Gbits/s

Connectors

1 ETH

4 USB v3.0

2 USB v2.0

1 Display Port v1.2

1 HDMI v1.4

Screen

21.5'' (in) Dell Monitor E2216H

1920 x 1080 Full HD resolution

QC export format

csv files

Dimensions (HWD)

PC: 18.2 x 3.6 x 17.8 (cm)

Screen: 39.7 x 51.2 x 18.0 (cm)

Data Management
Data Management
Data management includes software and services that provide an interface between in vitro diagnostic (IVD) instruments and Laboratory Information System (LIS) or between instruments in the same work area.

REQUEST FOR INFORMATION

Do you have any questions or requests? Use this form to contact our specialists.
