Yumizen H550

Full Walk Away Hematology Solution for Small Mid-Size Laboratories

Choose Yumizen and you will stay zen!

The Yumizen H550 is a compact 6-Diff hematology analyzer with an auto sampling system which aims at providing a full walk away capability to a variety of clinical environments: hospitals, satellite labs, emergency care, small independent labs, doctors’ offices…

With safe sample management, the Yumzien H550 is able to deliver a one hour autonomy of 40 samples in racks. Additional benefits include; continuous loading, automatic sample mixing, positive identification of samples and a manual mode for STAT samples for both open and closed tubes. The latter will manage emergency and pediatrics demands for a variety of samples types.

Based on the innovative ‘3 reagent use’ technology with low consumption, the Yumizen H550 hematology system incorporates enhanced features with high added value for laboratories in terms of data management and traceability standards: flexible connectivity with both ASTM and HL7 communication standards and overlapping Quality Controls.

As new member of Yumizen H500 products family, the Yumizen H550 is tailored to improve operational efficiency in the laboratories and provide a rapid and comprehensive hematology diagnosis, to assist clinicians in the delivery of safe and effective patient care.

Segment: Medical
Division: Hematology
Base product
Manufacturing Company: HORIBA ABX SAS
  • Ideal for small-mid labs, satellites labs, emergencies and physician offices labs
  • Walk away of 40 tubes, continuous loading, STAT mode
  • Foot print system
  • User Friendly Interface
  • Easy Handling
  • Full 6 Diff Diagnosis
  • Secured Workflow
  • Cost Effective Hematology Solution
  • Rapid testing
  • Only 2 reagents use for Diff analysis
  • Whole blood 20 µL sampling
  • 27 parameters, CBC/DIF Analysis
  • Flags & alarms expert system
  • Proven technologies of impedance and optical detection

Technical

Weight

77 lbs / 36 kg

Power supply

100 to 240 V ( 10%), 50 to 60 Hz

Dimensions

24 x 20 x 26 in / 62 x 53 x 67 cm (HxWxD).

Printer

Compatible models with Linux drivers

Throughout

43 tests/hour

Screen

Colour LCD touch screen of 12.1 in

Data management

LinuxTM

Transmit patient & QC to LIS



Uni-directional or bi-directional connection

Communication Protocols: ASTM & HL7

Connection: RS232, Ethernet, USB



Memory

10,000 results + Graphics

3 controls level (low, normal, high)

Target values download (USB)



Quality Control

Management



Overlapping QC

Levey-Jennings Graphs

Radar Graphs

XB on 3 or 9 parameters

Compatible with QCP

Logs

Reagents, calibration, quality control, blank cycle, users, settings, service, communication



Samples

Parameters (27)

WBC, NEU# & NEU%, LYM# & LYM%, MON# & MON%, EOS# & EOS%, BAS# & BAS %, LIC# & LIC%*, RBC, HGB, HCT, MCV, MCH, MCHC, RDW-CV, RDW-SD*, PLT, MPV, PCT*, PDW*, P-LCC*, P-LCR*

Graphs

High-definition Diff matrix

PLT & RBC curves

Sample-Volume

CBC mode : 20 µL

DIFF mode: 20 µL

Stability

48 hours post-draw stability for CBC parameters, 24 hours post-draw stability for DIFF parameters

Operating sample mode

Automtic mode (rack) and manual mode (STAT samples)

Identification

Alphanumeric. Bar-code reader (optional)

 * RUO parameters (Research Use Only)



Results

Parameters

Presicion (% CV)

Linearity

WBC

< 3.0

0-300 109/L

RBC

< 2.0

0-8 1012/L

HGB

< 1.5

0-240 g/L

HCT

< 2.0

0.67 L/L

PLT (whole blood)

< 5.0

0-2500 109/L

PLT (PLT concentrate)

< 5.0

0-4000 109/L

Blood Cells Monitoring
Blood Cells Monitoring
Abnormalities of blood cells parameters are evaluated through laboratory testing in order to monitor quantitative acceptance criteria related to specific pathologies and/or applications.
Blood Cells Disorders Diagnostic
Blood Cells Disorders Diagnostic
Blood disorders are the pathologies which can affect the quantity as well as the functionality of the blood cells. The diagnosis of hematologic disorders is performed and based on the: - Medical history (symptoms) - Physical examination - Laboratory tests Blood cells disorders could affect Red Blood Cells, White Blood Cells and Platelets.
Infectious Screening
Infectious Screening
Infectious screening is the laboratory examination which can rapidly and early detect an infectious disease, with the intention of intervening and/or modifying the treatment.
