The result of 50 years of expertise in Raman spectroscopy, LabRAM Soleil™ offers unprecedented capabilities for Raman multimodal confocal imaging, in a compact footprint.
Due to the high level of automation implemented, high optical throughput, objective recognition, motorized switching mirrors, ultra-fast mapping capabilities with SmartSampling™ and QScan™, fast motorized 4-grating turret, high speed auto-alignment and new options offered by the LabSpec 6 software suite, the LabRAM Soleil™ is ready to work 24 hours a day with minimal human supervision.
Multimodal Confocal imaging in a compact footprint
LabRAM Soleil™ offers great variety of optical viewing modes and hyperspectral imaging features in a compact and laser safe design:
Focus on your job, it takes care of the rest!
Forget long and tedious preparation operations before getting your Raman image. LabRAM Soleil™ offers advanced automated functions and, in combination with the EasyImage™ wizard, it dramatically reduces parameter setting time and ensures maximum stability and reproducibility:
Ultrafast imaging: Raman imaging has never been so fast!
Due to a higher optomechanical stability, advanced and patented video Raman matching technology, LabRAM Soleil™ makes possible high-quality Raman imaging up to 100 times faster than a conventional Raman spectrometer.
Facing all analytical challenges:
From materials studies to polymers, and biological to pharmaceutical laboratories, LabRAM Soleil™ can be easily adapted for each application. Its advanced modularity and flexibility makes it a perfect Raman microscopy system, for both academic research laboratories and industrial quality control departments.
LabSpec6 software: harness LabRAM Soleil™ full power with ease!
LabSpec 6 software offers a great modularity with the exclusive LabStore Apps. Any user can configure his software according to his own needs. Efficiency and performance are combined with ease-of-use. The modern and intuitive design of the software makes it easier than ever to achieve a perfect Raman image. No need to be an expert anymore.
|Wavelength range||UV-VIS-NIR||Broadband high troughput achromatic mirror based system, optimized from 300 nm to 1600 nm without changing optics.|
|Standard Laser Wavelengths||325, 405, 473, 532, 638, 785 nm||Typical lasers for Raman and PL. Other wavelengths upon request.|
|Spectrometer scanning speed||Up to 400 nm/s||With 600g/mm grating, mounted on standard Turbodrive 4-grating turret, for fast Raman, PL and upconversion luminescence spectral map acquisitions.|
|Number of gratings||unlimited||4-grating exchangeable motorized turret.|
|Fast Imaging||<1ms/spectrum||SWIFT, SWIFT XS EMCCD, SWIFT repetitive, SWIFT eXtended Range and SmartSampling for ultrafast imaging.|
|3D confocal slicing with laser lightsheet illumination||QScan (patent)||Typical 2 μm thick 100 x 100 μm2 laser lightsheets for large area 2D/3D confocal imaging.|
|Low wavenumber cut-off||5 cm-1||With optional VBG filters, >70% transmission.|
|Standard wavenumber cut-off||30 cm-1||With edge filters for 532, 638 and 785 nm wavelengths, injection rejection, >99% transmission.|
|High wavenumber cut-off for PL||1600 nm||Scanning Czerny Turner spectrometer with 2 motorized detector ports for CCD and InGaAs array detectors.|
|Laser auto-alignment procedure||15 s||Optional ultrafast sample-independant laser auto-alignment allowing remote maintenance.|
|Built-in lasers||Up to 4 Solid-state lasers||NUV to NIR wavelengths available.|
|External lasers||Unlimited||For large gas and ultrafast lasers typically.|
|Spectroscopic motorized modalities||Up to 6 laser filters||Raman, PL, ULF, Upconversion luminescence…|
|Rayleigh Filter orientation||Individual filter computer controlled||Factory preset & user adjustable angle to adapt with sample reflectivity.|
|AFM / SEM coupling||Yes||Built-in horizontal exit for direct Atomic Force Microscope coupling, optional fiber entrance for SEM coupling with RCLUE.|
|Operating temperature range||18-28 °C||Non condensing|
|Dimensions (W x D x H in mm)|
898 x 797 x 806
|~1 cubic meter, including lasers, CDRH enclosure, electronics and cooling to save space in your laboratory|
|Power consumption||< 600 W for a fully loaded configuration||Eco-friendly and safe design, with built-in class 1 enclosure, low power consumption electronics and cooling, 1 power cable EU / US type|
