XploRA™ PLUS

Raman Spectrometer - Confocal Raman Microscope

Raman imaging has never been so fast!

Incorporating unique and powerful functions in a reliable, high performance system, ideally suited to the research and analytical lab, the XploRA PLUS is our best multi-sample, multi-user Raman microscope ever.

It is fully confocal, not compromising image quality, spatial or depth resolution. The SWIFT Fast Raman images are the fastest fully confocal Raman images available, typically 10x faster than conventional Raman imaging.

The simplicity and power of the XploRA PLUS is unmatched with an enhanced range of options such as multiple laser wavelengths, EMCCD detection, Raman polarisation and even Raman-AFM combination.

Segment: Scientific

Division: Molecular and Microanalysis

Manufacturing Company: HORIBA France SAS

SWIFT^TM10x faster Raman imaging
Improved detection and sensitivity
Full Confocality for complete image detail
Full optical microscope so you can see your samples
Maximum detail, resolution and range for enhanced spectroscopy
HORIBA’s OneClick easy Raman analysis
NIST traceable and patented Autocalibration options for validated results
Ultimate optical stability- robust, reliable, long term operation
Automated operation offering simple, powerful reliability
2 year base unit warranty as standard

Future-proof Expansion

Compatible with atomic force microscopes for combined Raman-AFM and TERS (Tip Enhanced Raman Spectroscopy)
Multiple laser wavelengths – ensures optimal results and minimised fluorescence interference from the widest range of sample types
Full system automation with software control and intuitive operation – non-expert operators can get results fast
Comprehensive Raman spectral libraries for fast Raman chemical identification
Automated particle location and chemical ID with ParticleFinder
Suitable for high throughput screening measurements with MultiWell module.

Faster Raman YES with XY stage
SWIFT™ Imaging
/ SWIFTXS (with
EMCCD)

Confocal Imaging 0.5 μm XY

Routine operation OneClick Auto
Automation

Full Microscope Upright

Resolution Standard + High
> 1.4 cm-1 FWHM

Multi-laser 532, 638, 785 nm
Options others on request

Insights into thrombosis mechanisms using high resolution SERS

Direct_identification_of_clinically_relevant_microorganisms

Raman Analysis of Single Bacteria Cells

Traditionally, Raman has been a technique of the material scientist, physicist or chemist, but as instrumentation continues to evolve, the power of Raman in biological and medical applications is fast being realized, not least because of the high information content provided and an excellent tolerance for water.

Raman Investigation of Micro-organisms on a single cell level

Raman Imaging of monkey brain tissue

Fast and non-invasive methods for clinical and non clinical investigations for biological tissue are more and more required. Raman imaging at micro scale can answer to crucial questions about the monkey brain tissue morphology and structural evolution.

Raman Analysis of Sperm Nuclear DNA Integrity

Raman Spectroscopy was evaluated as a non-invasive method of analysis of sperm DNA and the influence of UV irradiation on the sperm. The results show that Raman Spectroscopy, combined with multivariate analysis provide the reproducible and accurate information on DNA of sperm and the effect and location of damage.

SERS Analysis of single living lymphocytes

Char of Compounds in a pharmaceutical drug product

Char of Compounds in a pharmaceutical drug product

Characterization and mapping of active pharmaceutical ingredients and excipients in a tablet using Raman and IR spectroscopy

Characterization and mapping of active pharmaceutical ingredients and excipients in a tablet using Raman and IR spectroscopy

Polymorphy in pharmaceuticals by Raman Spectroscopy

Raman Analysis and characterization of pharmaceuticals

Raman Microscopy in Pharmaceutical Salt Analysis

Pharmaceutical and crystallographic samples typically require detailed characterization and analysis to optimize a samples stability, physical properties and indeed general efficacy where an active drug substance is involved.

Investigating the atherosclerosis process by monitoring lipid deposits including cholesterol and free fatty acids

Transmission Raman Spectroscopy

Pharmaceuticals_under_humidity_controlled_atmosphere

Soap_compound_investigation_by_Raman_mapping

SERS for Intracellular Imaging

In Vivo Raman measurements of Human Skin

Confocal Raman spectroscopy is beginning to be recognized as a high potential technique for the non invasive study of biological tissues and human skin under in vivo conditions. Raman spectroscopy can be applied to obtain information regarding the molecular composition of the skin down to several hundred micrometers below the skin surface.

SWNT Quality Control by Raman Spectroscopy

Raman has shown a high potential in characterising the SWCNTs' structure. The correlation between knowledge about structure with physical and chemical properties about the tubes make the technique extremely powerful to control the quality of the SWCNTs for specific applications. Raman spectrometer capabilities like spatial resolution, spectral resolution and excitation wavelength versatility have been examined. Beside Raman, preliminary fluorescence studies are describing the potential of the technique.

Graphene Studies using Raman Spectroscopy

Graphene is a new nanomaterial which may partially replace silicon in microcircuits and computer chips in the future. In order to better understand its quality characteristics, fast reliable techniques that deliver the right property measures are needed. Raman spectroscopy has emerged as a key technique for studying this exceptional material.

Coloured Diamond Defect Idenditication by Raman Diffusion and Photoluminescence

The colour enhancement treatment on native brown and yellow diamonds can be highlighted by Photo Luminescence analyses performed with the Raman spectrometer LabRAM HR. The PL signature of green and violet diamonds has also been recorded. The defect centres responsible of the colour of the diamonds have all been detected and assigned. This proves the Raman spectrometer to be a very good tool to investigate the fine defects in the Diamond structure by Photoluminescence analysis.

Derivation of Physical Parameters from Raman Spectra of Hard Carbon Films

The Raman spectra of elemental carbon materials are known to be sensitive to polymorphy. For hard carbon films, the spectra of amorphous and diamond-like carbons can be band-fit to separate the contributions of the "graphitic carbon" (G band) from the "disordered carbon" (D band). The spectral behaviour of carbon films has been empirically correlated with thin film physical properties such as hardness, durability, optical transparency, electrical conductivity, thermal conductivity and corrosion resistance, and can be of use for prediction of these properties without extensive alternative testing. The DiskRam has been designed to automate the collection of Raman spectra from hard carbon coatings on computer hard disk media and the extraction of parameters that are well correlated with the properties of the films. The extracted information is output in spreadsheet format for SPC at a manufacturing facility.

Impact of Raman Spectroscopy on Technologically Important Forms of Elemental Carbon

The Raman spectra of the various forms of elemental carbon are very sensitive to the type of nearest neighbour bonding, and to intermediate and long range order. In many cases Raman spectroscopy is the technique of choice for characterization of carbon materials. Correlation of Raman spectral features with tribological properties can facilitate the deposition of carbon films.

Number of Layers of MoS2 Determined Using Raman Spectroscopy

The two methods - Analysis of fingerprint modes (intralayer) and Analysis of low-frequency modes (interlayer) - give complementary results and allow the determination of the number of MoS2 layers. Method 2 (using low frequency modes) gives excellent contrast; however it does not show single layer regions (which is related to the nature of the modes, rising from interaction between at least two layers). Method 1 (using fingerprint modes) shows all the layers, but the contrast is poorer, particularly for higher numbers of layers. The best result can be obtained combining the two methods. All the measurements (low-frequency and fingerprint) were done using ultra-low frequency ULFTM filters which allow a high throughput measurement in a full Raman range, down to <10 cm-1.

Characterization of MoS2 Flakes using TEOS

Both TEPL and TERS images are well correlated with AFM morphological images obtained simultaneously, and all are consistent in revealing the nature (number of layers) of MoS2 flakes. Upon deconvolution, the TEPL signal is even capable of revealing local inhomogeneities within a MoS2 flake of 100 nm size. Kelvin probe measurement supports TEPL and TERS measurements and adds to the power of such tip-enhanced combinative tools. TEOS characterization of 2D materials is likely to contribute to further deployment of these materials into commercial products through a better understanding of their electrical and chemical properties at the nanoscale.

Combined Raman and Photoluminescence Imaging of 2D WS2

Raman and photoluminescence spectroscopy reveal different aspects of the solid state structure of 2D materials. Raman and photoluminescence imaging performed simultaneously with one instrument reveals the spatial variation of the solid state structure and electronic properties of 2D crystals that is not revealed in reflected white light imaging. That ability should allow materials scientists to better design and fabricate electronic and optoelectronic devices based upon 2D crystals.

Observing Oxidating Kinetics on an aluminium alloy surface with Fluorescence mapping

Archaeometric analysis of ancient pottery in a church

Archaeometric analysis of ancient pottery

The non destructive and in-situ analysis of pigments

Strain Measurements of a Si Cap Layer Deposited on a SiGe Substrate, Determination of Ge Content

Raman spectroscopy is a very well suited technique to determine both Ge fraction and strain in SiGe layers and Si cap layers. Moreover the possibility of using both UV and visible excitation lines on the same instrument is essential to study structures made up of a Silicon cap layer on top of a SiGe layer. The relative Ge content in the constant Si1-xGex layer is calculated from the visible Raman spectrum and the strain of the cap Si layer is derived from the UV Raman spectrum.

The coupling of the power of confocal Raman microscopy to the inverted sampling geometry has enabled detailed investigations to be made of solvent and water based coating systems, providing important information on the processes and chemistry that occurs at the coating interface and within.

Localisation of Polymeric Phases by Raman Microscopy Mapping Components of a Blend in a Plane and Depth Profiles of Laminated Film

Blending, an alternative method for engineering products that combines the properties of polymer types is a physical mixing. It has the advantage of being not only simple and inexpensive, but also allows for re-cycling used material. Incompatibility or non-miscibility of the differing chemical components is often an issue in the final performance of the polymer product. The first part of this note concerns the dispersion of the two components in a polyethylene-polybutylene terephthalate blend. The chemical imaging capabilities of the LabRAM are used to get this information. The second part deals with the depth analysis of laminated films made of different polymer layers.

Raman Characterization of Polymers in Industrial Applications

Recent developments in Raman instrumentation have made the technique easier to use, more compact, and more affordable. Consequently, all of the demonstrated potential of the spectroscopy for industrial uses can now be exploited, including its use in combination with statistical methods for concentration calibrations.

Real-time Monitoring of Polymerisations in Emulsions by Raman Spectroscopy - Modelling and Chemometrics

Raman spectra, in conjunction with Multivariate (Chemometric) Analysis, have been demonstrated to provide real-time information on the progress of a polymerisation reaction. As shown by this example, these results can provide unexpected information on the details of the reaction. in this case, the inequivalent reaction rates of the two monomers. Such information ultimately enables the process engineer to optimise his process.

Transmission Raman Spectroscopy: Review of Applications

The transmission design has demonstrated to be the technique of choice whenever Raman spectral information of a bulk material is required. It has already proven its utility for pharmaceutical applications, as tablets or even powder mixtures are good candidates for this measurement mode. However, transmission Raman might be applied successfully to other sample types, such as polymers, bio-tissues or any translucent material, and can be envisaged for evaluating the content of product inside a package. In addition, as TRS provides a global spectral information of the measured sample, it will be a technique of choice when quantitative evaluation of mixtures is needed.

Using Chemometrics and Raman Spectra for Quantitative Predictions of Physical and Chemical Properties of Polymers

As far as polymeric fibres are concerned, slight modifications of Raman features are directly related to differences in the molecular orientation and the degree of crystallinity of the fibres. To utilize these subtle spectral changes and correlate them with physical properties of the polymer, one is obliged to use Chemometrics on the Raman spectra. The resulting synergism between Raman spectroscopy and Chemometrics will provide a powerful tool for monitoring and control of manufacturing of polymeric materials.

Raman Imaging of Holographic Gratings Inscribed on Polymer Thin Films

Using holographic techniques we have structured the surface in a one step procedure (no wet nor photocuring processing ) along the X and Y directions. A grating is first inscribed with grooves along the X direction, the sample is rotated by 90° and a second grating is inscribed with grooves along the Y direction. The intensity of the 1st diffracted orders is monitored to have equal intensities in both X and Y directions.

$Milk compounds characterization by optical spectroscopies and laser diffraction$

In the food industry, the compounds characterization is a critical step to ensure the quality of the products or to provide information to customers which can be sensitive to allergies. In this application note, we showed how optical spectroscopies and laser diffraction can help for food compounds characterization, especially on a specific product, i.e. milks.

Brake Dust Measurement

A series of legislative measures has significantly reduced the amount of emissions that is being emitted by internal combustion engines of light and medium-duty vehicles.

Spectroscopic Methods for Sunscreens Characterization

This Application Note outlines three different kinds of spectroscopic tools being used for the characterization of sunscreens, and discusses the obtained results. These include Fluorescence spectroscopy for photoactivity, Particle Size analysis for composition and Raman microscopy for formulation investigation.
