STARS HDEET

Heavy-Duty 엔진 배출가스 테스트용 테스트 자동화 시스템

STARS HDEET는 입법 표준을 준수하는 heavy-duty 엔진 배출가스 테스트용 테스트 자동화 시스템으로 효율적인 시험 주기 실행, 배출 장비 제어, 결과 계산 및 보고를 제공합니다. ​

​뛰어난 설계로 연구 개발, 생산 적합성 및 인증 테스트에 필요한 다양한 요구사항을 충족시킵니다. 최근 heavy-duty 엔진 배출가스 테스트의 복잡성은 날이 갈수록 증가하고 있으며 배출 규제의 복잡성 증가, 온실가스에 대한 새로운 표준 등을 모두 고려해야 합니다. ​

​STARS HDEET는 모든 종류의 엔진 개발 테스트 작업을 자동화하여 완벽한 배출가스 규제 인증 절차를 제공하며, 이러한 복잡성 해결에 기여하고 있습니다.

Segment: Automotive

Selection of countries and territories where this product is available:
Antigua and Barbuda
View the complete list here.

STARS HDEET increases test cell efficiency and productivity from test configuration to final report generation, always keeping the highest quality level to give absolute confidence in the test results.

Powerful

STARS HDEET can be extended to run custom cycles and to control additional measurement devices which are needed when emissions test cycles are used as part of the base engine or calibration development process.

Flexible

With our proven experience in engine emission testing, STARS HDEET has been designed so that individual test options can either be selected by the operator for each test or taken from pre-defined default settings.

Efficient

Preloaded with regulatory cycles, configuration data and results calculations for a wide range of engine applications, STARS HDEET is a ready-to-use solution. STARS HDEET guides the user through the test configuration with minimal required input data, minimising the risk of configuration errors.

Main emission standards

On-highway heavy-duty engine regulations

  • US 40 C.F.R Part 86 Subpart N
  • EU 582/2011 amended for Euro VI (UNECE R49 Rev 6)
  • JAPAN Technical Standard 11-3-41 (WHDC)
  • CHINA GB 17691-2018
  • INDIA AIS 137 Part-4 (Bharat Stage VI)


Greenhouse gas emissions

  • US 40 C.F.R Part 1036 / 40 C.F.R Part 1037

Non-road mobile machinery regulations

  • US 40 C.F.R Part 1039
  • US 40 C.F.R Part 1048
  • US 40 C.F.R Part 1042
  • EU Regulation 2017/654, amended by Regulation 2018/989
  • JAPAN Technical Standard 11-3-43
  • CHINA HJ 1014-2020 / GB 20891-2014
  • INDIA AIS 137 Part-7 - A1 (Bharat Stage IV)
  • INDIA AIS 137 Part-7 - A2 (Bharat Stage V)


Test Procedures

  • Engine power map test
  • Discrete modal emissions cycles
  • Ramped modal emissions cycles
  • Transient emissions cycles
  • Cold start / soak / hot start procedure
  • EPA GHG Phase 2 mapping procedures
  • Pre-test emissions system check procedures


Analysis and Reporting

  • Power map calculations
  • Cycle denormalisation
  • Post-test control and measurement system validation
  • Emissions mass calculations
  • Configurable Excel report
  • Data import / export for GEM simulation for EPA GHG Phase 2
