LAQUAtwin 4ECSalt-11

Pocket Water Quality Meters

Your lab-in-a-pocket
HORIBA's unique compact meter integrates the electrode, display and sample container to enable simple, effective on-site testing by direct measurement from a single drop.

Segment: Scientific

Division: Water Quality

Fabricant: HORIBA Advanced Techno Co., Ltd.

The only pocket meter that directly measures conductivity in 0.12ml sample and converts it into salinity or salt concentration. No need for a beaker to calibrate the meter or measure a sample. Just place few drops of the standard or sample onto the sensor. This procedure saves you time and prevents wasting your precious sample.

Minimum sample volume: 0.12ml
Salinity and temperature display
Up to 2 calibration points
Auto calibration
Auto standard recognition: 0.50 & 5.00 % NaCl
Auto temperature compensation: 2%/ºC fixed
Temperature adjustment: 5 to 40.0 ºC
2 Salinity curves: NaCl & Seawater
Auto stable / auto hold measurement
Auto power off (30 mins)
Low battery indicator
Rated IP67 waterproof and dustproof
Replaceable sensor
400 Hours battery life: continuous use without backlight
Material: ABS epoxy body & titanium coated with carbon sensor
Display: custom (monochrome) digital LCD with backlight
Operating conditions: 5 to 40°C, 85% or less relative humidity
Warranty: 2 years - meter, 6 months - sensor
Packed in handy carrying case
Supplied with 0.5% & 5.0% NaCl standards (14ml each), conditioning solution (4ml), dropper, instruction and quick manuals

Model	4ECSalt-11
Measurement Principle	4 AC bipolar method
Minimum Sample Volume	0.12ml
Salinity Range & Resolution	0.0 to 100.0 g/L (ppt): 0.1 g/L (ppt) 0.00 to 10.00%: 0.01%
Calibration Points	Up to 2
Calibration Curves	NaCl & Seawater
Accuracy	±2% full scale (0.0 to 9.9 g/L) ± 4% full scale (10.0 to 100.0 g/L)
Temperature Display	0 to 50.0 ºC
Temperature Adjustment	5 to 40.0 ºC
Display	Custom (monochrome) digital LCD with backlight
Operating Temperature	5 to 40.0 ºC
Operating Humidity	85% or less relative humidity (no condensation)
Power	CR2032 batteries (2)*
Battery Life	Approx. 400 hours in continuous use without backlight
Material	ABS epoxy body & titanium coated with carbon sensor
Outer Dimensions	164 × 29 × 20 mm (excluding projections)
Mass	Approx. 45 g (only meter, excluding batteries)
Functions	Auto Calibration Auto Standard Recognition Temperature Adjustment (2%/ºC fixed) Temperature Calibration Auto Hold / Auto Stable Measurement Switchable Backlight Automatic Power Off (30 mins) Low Battery Indicator Rated IP67 waterproof and dustproof Replaceable sensor
